Fail locked operation. The door can only be opened while a contact is made.

When the door is closed, the keep with fixing plate holds the door leaf in place too. The glass door must have a stop for the door leaf or be actuated by a door closer with adjustable closing force. In the case of two-leaf glass doors, a strike must be integrated at the top in the door frame for each leaf (not suitable for swing doors).
Models 914 and 914ZY are fastened with a securing pin to ensure that the strike latch is not locked unintentionally when the door is open.

DIN right and left installation thanks to 180° rotation.
With 12/24V switch and supressor diode (e.g. for use with access control systems).
Thickness can be adjusted between 9-12 mm (FaFix).

Diode (05)
Adjustable latch (FF, FaFix)
Adjustable strike (F, Fix)
Monitoring contact (RR)
