Fail unlocked operation.
The electric strike is locked for as long as the power is on. If the power is switched off or if there is a power cut, the electric strike latch can be moved and the door can be opened.

When the door is closed, the keep with fixing plate holds the door leaf in place too. The glass door must have a stop for the door leaf or be actuated by a door closer with adjustable closing force. In the case of two-leaf glass doors, a strike must be integrated at the top in the door frame for each leaf (not suitable for swing doors).
Models 934 and 934ZY are fastened with a securing pin to ensure that the strike latch is not locked unintentionally when the door is open.

DIN right and left installation thanks to 180° rotation.
With 12/24V switch and supressor diode (e.g. for use with access control systems).
Thickness can be adjusted between 9-12 mm (FaFix).

Diode (05)
Adjustable latch (FF, FaFix)
Adjustable strike (F, Fix)
Monitoring contact (RR)
